TKS Series Turf Roller

In some sports fields and public green spaces, the lawns are low and neat and very beautiful. After scientific maintenance, some green lawns have greatly improved their ornamental properties. Rolling lawn not only promotes the growth of the lawn, but also makes the lawn more tidy and beautiful, allowing people to better pace around the lawn.

What is lawn rolling?

Lawn rolling is the operation of rolling and pressing on the lawn with a turf roller machine. After rolling, the density of the lawn can be increased and the lawn can be smoother.

Introduction

KASHIN Turf Roller’s Advantage

1. Large, medium-sized self-propelled green rolling machine. KASHIN Turf roller has two independent parts, the left and right half shafts of the gearbox are driven independently, the chain is driven by the left and right half rollers, and the left and right clutch handles control the power steering, which is light and convenient to operate. This is a design highlight that distinguishes this product from other similar products. One-hand control makes it easy to steer, and you can easily turn 360 ° by holding the left (right) clutch.

2. KASHIN Turf Roller’s gearbox with three forward gears and one reverse gear (F3+R1) is adopted, which can facilitate the rapid movement of the equipment to the work place and solve the shortcomings of slow movement of imported equipment in non-working state.

3. KASHIN Turf Roller’s weight is adjusted by adding water, sand and other carriers. The left and right half sleeves and the drum belong to different structural spaces, which avoids the influence of adding water and sand to the sleeve bearing.

4. KASHIN Turf Roller uses 9HP high-power gasoline engine to increase the climbing ability. Auxiliary support rollers are respectively arranged at the front and back to facilitate the operation control of the equipment.

5. The shifting control lever adopts rigid design, the other left and right steering and throttle are controlled by soft cable, the brake adopts hydraulic disc brake, all the control mechanism handles are within easy reach, showing the humanized design concept.

6. Front and rear auxiliary support wheels ensure safe and light operation for the operator.

7. The height of the control handle is adjustable, suitable for operators of different heights.

Specification

Structure weight	400 kg	500 kg	680 kg	800 kg
Model	TKS56	TKS72	TKS83	TKS100
Working width	1430 mm	1830 mm	2100 mm	2500 mm
Roller diameter	600 mm	630 mm	630 mm	820 mm
With water	700 kg	1100 kg	1350 kg	1800 kg
